Product Features
Good appearance, space saving,large dust capacity
Light weight, convenient installation and replacement
Injecting jelly into the liquid tank, environment friendly and reliable sealant efficiency.
High efficiency,low resistance.
Low operation cost.
Excellent sealing.
Application
Widely used as the terminal filtration of clean room. Or as the filtration unit in the clean room equipment.
Material and Operation Conditions
Filter Media | Fiberglass |
External Frame | Aluminum |
Partition | Hot melt adhesive |
Sealant | Polyurethane adhesive |
Max. Temperature | 85℃ |
Max. Humidity | 80%RH |
Specification and technical parameters
ModelNo. | Size(mm) (L*W*H) | Rated Air flow (m³/h) | Velocity (m/s) | Initial resistance (pa) | Final Resistance |
GU | 320*320*95 | 160 | 0.45 | ≤110 | 300 |
GU | 484*484*95 | 400 | 0.45 |
GU | 570*570*95 | 550 | 0.45 |
GU | 610*305*95 | 300 | 0.45 |
GU | 610*610*95 | 600 | 0.45 |
GU | 915*610*95 | 900 | 0.45 |
GU | 1170*570*95 | 1080 | 0.45 |
GU | 1220*610*95 | 1200 | 0.45 |
Can be customized according to customer requirements |
